| 2032H No Polarized |
Housing |
|
| 2032H Polarized |
Housing |
|
| 2001PS |
Straight Headers |
|
| 2002PS |
Straight Headers |
|
| 2003PR |
Right Angle Headers |
|
| 2004PR |
Right Angle Headers |
|
|
|
|
| 2032H |
|
 |
| Current rating : 1A AC,DCVoltage rating : 250V AC,DCTemperature range : -25°C to +85°C(including temperature rise)Contact resistance : Initial value/10mΩ Max.After environmental testing/20mΩ Max.Insulation resistance : 500MΩ MIN.Withstanding voltage : 1500V AC/minuteApplicable wire : AWG#26-28 |
|
|
|
|
|
|
|
|
